Square D 100A 12-Space 24-Circuit Main Breaker Load Center with 15 Terminal Ground Bar Kit

The Square D Homeline 100 Amp 12-Space 24-Circuit Indoor Main Breaker Load Center and Ground Bar Kit bundle combines a robust 100A main breaker panel for power distribution with a 15-terminal ground bar accessory to help manage electrical grounding needs. The Homeline load center provides a 100A, 120/240V single phase panel with 12 circuit breaker spaces. It can accommodate full-size, tandem, or quad breakers and has a 22kA breaking capacity. The load center features 3-wire connections, accepting 6 AWG to 2/0 AWG copper and aluminum wires. It also includes a flush/surface indoor cover and distributed neutral bar. The companion 15-terminal ground bar kit is designed specifically for use with Square D panels. Its 15 terminals can each accept #14-#4 copper wires or #12-#4 aluminum wires, providing flexible ground wire management. Together, this bundle delivers the core infrastructure to set up a residential or light commercial grade electrical service panel with plenty of capacity, plus integrated grounding. The Homeline panel's high amperage and number of spaces allow for expansion, while the ground bar ensures proper system grounding for safety and reliability.

• 100 Amp main breaker load center with full neutral bar distributes power to circuits
• Accepts up to 2/0 AWG wire and provides 22 kA breaking capacity for overload protection
• 12 circuit spaces fit full-size, tandem and quad breakers to customize your setup
• Ground bar kit with 15 terminals connects equipment grounds to the load center
• Indoor enclosure with combination flush/surface cover mounts easily
